Smokeoven twin configuration

For medium and large scale operations

Dual-chamber cabinets have considerable advantages over single cabinet operations. Though there is only one cabinet in use during normal operations, the second cabinet is ever ready to be used at peak times. Thus there is no need to have a large cabinet hot at all times – you save on energy costs. On top you can smoke different food at the same time at different temperatures and without compromising taste. Economical charging is possible with trolleys.

Basic configuration (each)
50 mm insulated double wall
Thermostat
Power switch
Automatic timer
3 heating levels 2/4/6 kW
Built-in thermometer in door
Switch for side mounted heater
Solid door latches

Special accessories see below

Technical Specifications:
Width: 2060 mm
Width, single chamber: 1030 mm
Depth, with door hinges: 800 mm
Height: 2000 mm
Voltage: 3 x 380 V / 230 V
Power: 15 KW
Chimney: Ø 120 mm
